Complete specification
| Section | Specification | Details |
|---|---|---|
| Network | Speed | HSPA 42.2/5.76 Mbps, LTE (2CA) Cat13 400/75 Mbps |
| 2G bands | GSM 850 / 900 / 1800 / 1900 | |
| 3G bands | HSDPA 850 / 900 / 1700(AWS) / 1900 / 2100 | |
| 4G bands | 1, 2, 3, 4, 5, 7, 8, 12, 13, 17, 25, 26, 28, 38, 40, 41, 66 | |
| Technology | GSM / HSPA / LTE | |
| Launch | Status | Discontinued |
| Announced | 2020, April 06. Released 2020, May 19 | |
| Body | SIM | · Nano-SIM · Nano-SIM + Nano-SIM |
| Weight | 180 g (6.35 oz) | |
| Dimensions | 162.2 x 75.6 x 8.4 mm (6.39 x 2.98 x 0.33 in) | |
| Display | Size | 6.53 inches, 104.7 cm2 (~85.4% screen-to-body ratio) |
| Type | IPS LCD, HDR | |
| Resolution | 1080 x 2340 pixels, 19.5:9 ratio (~395 ppi density) | |
| Platform | OS | Android 10, upgradable to Android 11, TCL UI |
| CPU | Octa-core (4x2.0 GHz Kryo 260 Gold & 4x1.8 GHz Kryo 260 Silver) | |
| GPU | Adreno 610 | |
| Chipset | Qualcomm SM6125 Snapdragon 665 (11 nm) | |
| Memory | Internal | 64GB 6GB RAM, 128GB 6GB RAM, 256GB 6GB RAM |
| Card slot | microSDXC (uses shared SIM slot) | |
| [memoryother] | 64GB eMMC 5.1, 128/256GB UFS 2.1 | |
| Main Camera | Quad | 48 MP, f/1.8, 26mm (wide), 1/2.25", 0.8µm, PDAF 8 MP, f/2.2, 13mm (ultrawide), 1/4.0", 1.12µm 2 MP (macro) Auxiliary lens |
| Video | 4K@30fps, 1080p@30/120fps | |
| Features | Dual-LED flash, HDR, panorama | |
| Selfie camera | Video | 1080p@30fps |
| Single | 16 MP, f/2.2, 28mm (wide), 1/3.06", 1.0µm | |
| Sound | 3.5mm jack | Yes |
| Loudspeaker | Yes | |
| Comms | NFC | Yes |
| USB | USB Type-C 2.0, OTG | |
| WLAN | Wi-Fi 802.11 a/b/g/n/ac, dual-band, Wi-Fi Direct | |
| Radio | FM radio | |
| Bluetooth | 5.0, A2DP, LE, aptX | |
| Positioning | GPS, GALILEO | |
| Features | Sensors | Fingerprint (rear-mounted), accelerometer, gyro, proximity, compass |
| Battery | Type | Li-Po 4000 mAh |
| Misc | Price | About 140 EUR |
| Colors | Arctic White, Mariana Blue | |
| Models | T770H, T770B, 4187U |
