Complete specification
| Section | Specification | Details |
|---|---|---|
| Network | Speed | HSPA 42.2/5.76 Mbps, LTE (5CA) Cat16 1000/150 Mbps, 5G 2.3 Gbps DL |
| 2G bands | GSM 850 / 900 / 1800 / 1900 | |
| 3G bands | HSDPA 850 / 900 / 1700(AWS) / 1900 / 2100 - T790Y | |
| 4G bands | 1, 3, 5, 7, 8, 20, 28, 32, 38, 40, 41 - T790Y | |
| 5G bands | 1, 3, 8, 28, 77, 78 SA/NSA - T790Y | |
| Technology | GSM / HSPA / LTE / 5G | |
| Launch | Status | Discontinued |
| Announced | 2020, April 06. Released 2020, July 27 | |
| Body | SIM | · Nano-SIM · Nano-SIM + Nano-SIM |
| Build | Glass front, glass back, aluminum frame | |
| Weight | 210 g (7.41 oz) | |
| Dimensions | 163.7 x 76.6 x 9 mm (6.44 x 3.02 x 0.35 in) | |
| Display | Size | 6.53 inches, 104.7 cm2 (~83.5% screen-to-body ratio) |
| Type | IPS LCD, HDR10, 450 nits (typ) | |
| Resolution | 1080 x 2340 pixels, 19.5:9 ratio (~395 ppi density) | |
| Platform | OS | Android 10, TCL UI |
| CPU | Octa-core (1x2.4 GHz Kryo 475 Prime & 1x2.2 GHz Kryo 475 Gold & 6x1.8 GHz Kryo 475 Silver) | |
| GPU | Adreno 620 | |
| Chipset | Qualcomm SM7250 Snapdragon 765G 5G (7 nm) | |
| Memory | Internal | 128GB 6GB RAM |
| Card slot | microSDXC (uses shared SIM slot) | |
| [memoryother] | UFS 2.1 | |
| Main Camera | Quad | 64 MP, f/1.9, 26mm (wide), 1/1.72", 0.8µm, PDAF 8 MP, f/2.2, 13mm (ultrawide), 1/4.0", 1.12µm 5 MP (macro) Auxiliary lens |
| Video | 4K@30fps, 1080p@30/60/120fps, gyro-EIS | |
| Features | Dual-LED flash, HDR, panorama | |
| Selfie camera | Video | 1080p@30fps |
| Single | 16 MP, f/2.2, 26mm (wide), 1/3.06", 1.0µm | |
| Sound | 3.5mm jack | Yes |
| Loudspeaker | Yes | |
| Comms | NFC | Yes |
| USB | USB Type-C 2.0, OTG | |
| WLAN | Wi-Fi 802.11 a/b/g/n/ac, dual-band, Wi-Fi Direct | |
| Radio | FM radio | |
| Bluetooth | 5.0, A2DP, LE | |
| Positioning | GPS (L1+L5), GLONASS, BDS, GALILEO, QZSS | |
| Features | Sensors | Fingerprint (rear-mounted), accelerometer, gyro, proximity, compass |
| Battery | Type | Li-Po 4500 mAh |
| Charging | 18W wired, QC3 | |
| Misc | Price | About 400 EUR |
| Colors | Chrome Blue, Mercury Gray | |
| Models | T790Y, T790H |
