Complete specification
| Section | Specification | Details |
|---|---|---|
| Network | Speed | HSPA 42.2/5.76 Mbps, LTE (2CA) Cat13 400/75 Mbps |
| 2G bands | GSM 850 / 900 / 1800 / 1900 | |
| 3G bands | HSDPA 850 / 900 / 1700(AWS) / 1900 / 2100 | |
| 4G bands | 1, 2, 3, 5, 7, 8, 20, 28, 38, 40, 41 | |
| Technology | GSM / HSPA / LTE | |
| Launch | Status | Discontinued |
| Announced | 2020, July 09. Released 2020, July 21 | |
| Body | SIM | · Nano-SIM · Nano-SIM + Nano-SIM |
| Weight | 166 g (5.86 oz) | |
| Dimensions | 164.9 x 74.7 x 8.4 mm (6.49 x 2.94 x 0.33 in) | |
| Display | Size | 6.52 inches, 102.6 cm2 (~83.3% screen-to-body ratio) |
| Type | LCD | |
| Resolution | 720 x 1600 pixels, 20:9 ratio (~269 ppi density) | |
| Platform | OS | Android 10, TCL UI |
| CPU | Octa-core 2.0 GHz Cortex-A53 | |
| GPU | PowerVR GE8320 | |
| Chipset | Mediatek MT6762 Helio P22 (12 nm) | |
| Memory | Internal | 128GB 4GB RAM |
| Card slot | microSDXC (uses shared SIM slot) | |
| Main Camera | Video | 1080p@30fps |
| Triple | 48 MP, f/1.8, 26mm (wide), 1/2.0", 0.8µm, PDAF 5 MP, f/2.2, 115˚ (ultrawide), 1.12µm Auxiliary lens | |
| Features | Dual-LED flash, HDR, panorama | |
| Selfie camera | Video | 1080p@30fps |
| Single | 8 MP, f/2.0, 26mm (wide), 1/4.0", 1.12µm or 13 MP, f/2.2, 26mm (wide), 1/3.1", 1.12µm | |
| Sound | 3.5mm jack | Yes |
| Loudspeaker | Yes | |
| Comms | NFC | Yes |
| USB | USB Type-C 2.0, OTG | |
| WLAN | Wi-Fi 802.11 a/b/g/n/ac, dual-band, Wi-Fi Direct | |
| Radio | FM radio | |
| Bluetooth | 5.0, A2DP, LE, aptX | |
| Positioning | GPS, GLONASS, GALILEO, BDS | |
| Features | Sensors | Fingerprint (rear-mounted), accelerometer, gyro, proximity, compass |
| Battery | Type | Li-Po 4000 mAh |
| Charging | 15W wired | |
| Misc | Colors | Black, Violet |
| Models | T766H_EEA, T766U, T766H, T766A, T766J |
