Complete specification
| Section | Specification | Details |
|---|---|---|
| Network | Speed | HSPA 42.2/5.76 Mbps, LTE (4CA) Cat16 1024/150 Mbps |
| 2G bands | GSM 850 / 900 / 1800 / 1900 | |
| 3G bands | HSDPA 850 / 900 / 1700(AWS) / 1900 / 2100 | |
| 4G bands | 1, 2, 3, 4, 5, 7, 8, 12, 17, 20, 34, 38, 39, 40, 41 | |
| Technology | GSM / CDMA / HSPA / LTE | |
| Launch | Status | Discontinued |
| Announced | 2018, May. Released 2018, June | |
| Body | SIM | Nano-SIM + Nano-SIM |
| Build | Glass front (Gorilla Glass 5), glass back (Gorilla Glass 5), aluminum frame (7000 series) | |
| Weight | 175 g (6.17 oz) | |
| Dimensions | 154.9 x 74.8 x 7.6 mm (6.10 x 2.94 x 0.30 in) | |
| Display | Size | 6.21 inches, 97.1 cm2 (~83.8% screen-to-body ratio) |
| Type | Super AMOLED, HDR10 | |
| Protection | Corning Gorilla Glass 5 | |
| Resolution | 1080 x 2248 pixels (~402 ppi density) | |
| Platform | OS | Android 8.1 (Oreo), upgradable to Android 10, MIUI 12 |
| CPU | Octa-core (4x2.8 GHz Kryo 385 Gold & 4x1.8 GHz Kryo 385 Silver) | |
| GPU | Adreno 630 | |
| Chipset | Qualcomm SDM845 Snapdragon 845 (10 nm) | |
| Memory | Internal | 64GB 6GB RAM, 128GB 6GB RAM, 128GB 8GB RAM, 256GB 6GB RAM |
| Card slot | No | |
| [memoryother] | UFS 2.1 | |
| Main Camera | Dual | 12 MP, f/1.8, 1/2.55", 1.4µm, dual pixel PDAF, 4-axis OIS 12 MP, f/2.4, 56mm (telephoto), 1/3.4", 1.0µm, AF, 2x optical zoom |
| Video | 4K@30/60fps, 1080p@30/120/240fps, 720p@960fps | |
| Features | Dual-LED flash, HDR, panorama | |
| Selfie camera | Video | 1080p@30fps |
| Single | 20 MP, f/2.0, (wide), 1/3", 0.9µm | |
| Sound | 3.5mm jack | No |
| Loudspeaker | Yes | |
| Comms | NFC | Yes |
| USB | USB Type-C | |
| WLAN | Wi-Fi 802.11 a/b/g/n/ac, dual-band, Wi-Fi Direct, DLNA | |
| Radio | No | |
| Bluetooth | 5.0, A2DP, LE, aptX HD | |
| Positioning | GPS (L1+L5), GLONASS (L1), BDS (B1), GALILEO (E1+E5a), QZSS (L1+L5) | |
| Features | Sensors | Infrared Face ID, fingerprint (rear-mounted), accelerometer, gyro, proximity, barometer, compass |
| Battery | Type | Li-Po 3400 mAh, non-removable |
| Charging | 18W wired, QC4 | |
| Misc | SAR | 0.70 W/kg (head) 1.66 W/kg (body) |
| Price | About 430 EUR | |
| Colors | Black, Blue, White, Gold | |
| Models | M1803E1A | |
| SAR EU | 1.01 W/kg (head) 1.32 W/kg (body) | |
| Our Tests | Camera | Photo / Video |
| Display | Contrast ratio: Infinite (nominal), 4.086 (sunlight) | |
| Loudspeaker | -29.1 LUFS (Average) | |
| Performance | AnTuTu: 217298 (v7), 341687 (v8) GeekBench: 8494 (v4.4), 2002 (v5.1) GFXBench: 33fps (ES 3.1 onscreen) | |
| Audio quality | Noise -93.9dB / Crosstalk -93.7dB | |
| Battery (old) | Endurance rating 86h |
