Complete specification
| Section | Specification | Details |
|---|---|---|
| Network | Speed | HSPA 42.2/5.76 Mbps, LTE Cat4 150/50 Mbps |
| 2G bands | GSM 850 / 900 / 1800 / 1900 | |
| 3G bands | HSDPA 850 / 900 / 1700 / 1900 / 2100 - D5803 | |
| 4G bands | 1, 2, 3, 4, 5, 7, 8, 13, 17, 20 - D5803 | |
| Technology | GSM / HSPA / LTE | |
| Launch | Status | Discontinued |
| Announced | 2014, September. Released 2014, September | |
| Body | SIM | Nano-SIM |
| Build | Glass front, glass back, plastic frame | |
| Weight | 129 g (4.55 oz) | |
| Dimensions | 127.3 x 64.9 x 8.6 mm (5.01 x 2.56 x 0.34 in) | |
| [bodyother] | IP68 dust tight and water resistant (immersible up to 1.5m for 30 min) | |
| Display | Size | 4.6 inches, 58.3 cm2 (~70.6% screen-to-body ratio) |
| Type | IPS LCD | |
| Protection | Shatter proof glass | |
| Resolution | 720 x 1280 pixels, 16:9 ratio (~319 ppi density) | |
| [displayother] | Triluminos display X-Reality Engine | |
| Platform | OS | Android 4.4.4 (KitKat), upgradable to 6.0 (Marshmallow) |
| CPU | Quad-core 2.5 GHz Krait 400 | |
| GPU | Adreno 330 | |
| Chipset | Qualcomm MSM8974AC Snapdragon 801 (28 nm) | |
| Memory | Internal | 16GB 2GB RAM |
| Card slot | microSDXC (dedicated slot) | |
| [memoryother] | eMMC 5.0 | |
| Main Camera | Video | 4K@30fps,1080p@60fps, 720p@120fps, HDR |
| Single | 20.7 MP, f/2.0, 25mm (wide), 1/2.3", 1.12µm, AF | |
| Features | LED flash, HDR, panorama | |
| Selfie camera | Video | 1080p@30fps |
| Single | 2.2 MP, f/2.8 | |
| Sound | 3.5mm jack | Yes |
| Loudspeaker | Yes, with stereo speakers | |
| Comms | NFC | Yes |
| USB | microUSB 2.0 (MHL TV-out), OTG, magnetic connector | |
| WLAN | Wi-Fi 802.11 a/b/g/n/ac, dual-band, Wi-Fi Direct, DLNA, hotspot | |
| Radio | Stereo FM radio, RDS | |
| Bluetooth | 4.0, A2DP, LE, aptX | |
| Positioning | GPS, GLONASS | |
| Features | Sensors | Accelerometer, gyro, proximity, compass, barometer |
| [featuresother] | ANT+ | |
| Battery | Type | Li-Ion 2600 mAh, non-removable |
| Charging | 18W wired, QC2 | |
| Stand-by | Up to 880 h (2G) / Up to 920 h (3G) | |
| Talk time | Up to 12 h (2G) / Up to 14 h (3G) | |
| Music play | Up to 110 h | |
| Misc | SAR | 0.95 W/kg (head) 1.10 W/kg (body) |
| Price | About 300 EUR | |
| Colors | Black, White, Green, Orange | |
| Models | D5803, D5833, SO-02G | |
| SAR EU | 0.69 W/kg (head) 0.90 W/kg (body) | |
| Our Tests | Camera | Photo / Video |
| Display | Contrast ratio: 942:1 (nominal), 2.616 (sunlight) | |
| Loudspeaker | Voice 65dB / Noise 62dB / Ring 73dB | |
| Performance | Basemark X: 12080 | |
| Audio quality | Noise -85.2dB / Crosstalk -85.3dB | |
| Battery (old) | Endurance rating 101h |
