Complete specification
| Section | Specification | Details |
|---|---|---|
| Network | Speed | HSPA 42.2/5.76 Mbps, LTE (3CA) Cat9 450/50 Mbps |
| 2G bands | GSM 850 / 900 / 1800 / 1900 - SIM 1 & SIM 2 (dual-SIM model only) | |
| 3G bands | HSDPA 800 / 850 / 900 / 1700(AWS) / 1900 / 2100 - F8331, F8332 | |
| 4G bands | 1, 2, 3, 4, 5, 7, 8, 12, 13, 17, 19, 20, 26, 28, 29, 32, 38, 39, 40, 41 - F8331, F8332 | |
| Technology | GSM / HSPA / LTE | |
| Launch | Status | Discontinued |
| Announced | 2016, September 01. Released 2016, October 03 | |
| Body | SIM | · Nano-SIM · Nano-SIM + Nano-SIM |
| Build | Glass front (Gorilla Glass 4), aluminum back, aluminum frame | |
| Weight | 161 g (5.68 oz) | |
| Dimensions | 146 x 72 x 8.1 mm (5.75 x 2.83 x 0.32 in) | |
| [bodyother] | IP68 dust tight and water resistant (immersible up to 1.5m for 30 min) | |
| Display | Size | 5.2 inches, 74.5 cm2 (~70.9% screen-to-body ratio) |
| Type | IPS LCD | |
| Protection | Corning Gorilla Glass 4 | |
| Resolution | 1080 x 1920 pixels, 16:9 ratio (~424 ppi density) | |
| [displayother] | Triluminos display X-Reality Engine | |
| Platform | OS | Android 6.0.1 (Marshmallow), upgradable to Android 8.0 (Oreo) |
| CPU | Quad-core (2x2.15 GHz Kryo & 2x1.6 GHz Kryo) | |
| GPU | Adreno 530 | |
| Chipset | Qualcomm MSM8996 Snapdragon 820 (14 nm) | |
| Memory | Internal | 32GB 3GB RAM, 64GB 3GB RAM |
| Card slot | microSDXC (uses shared SIM slot) - dual SIM model only | |
| [memoryother] | eMMC 5.1 | |
| Main Camera | Video | 4K@30fps, 1080p@60fps, 1080p@30fps (gyro-EIS) |
| Single | 23 MP, f/2.0, 24mm (wide), 1/2.3", PDAF | |
| Features | Laser AF, color spectrum sensor, LED flash, HDR, panorama | |
| Selfie camera | Video | 1080p@30fps |
| Single | 13 MP, f/2.0, 22mm (wide), 1/3" | |
| Features | HDR | |
| Sound | 3.5mm jack | Yes |
| Loudspeaker | Yes, with stereo speakers | |
| [optionalother] | 24-bit/192kHz audio | |
| Comms | NFC | Yes |
| USB | USB Type-C 2.0, OTG | |
| WLAN | Wi-Fi 802.11 a/b/g/n/ac, dual-band, Wi-Fi Direct, DLNA | |
| Radio | No | |
| Bluetooth | 4.2, A2DP, aptX, LE | |
| Positioning | GPS, GLONASS/ BDS (region dependent) | |
| Features | Sensors | Fingerprint (side-mounted), accelerometer, gyro, proximity, barometer, compass |
| Battery | Type | Li-Ion 2900 mAh, non-removable |
| Charging | 18W wired, QC3 | |
| Stand-by | Up to 600 h (2G) / Up to 610 h (3G) | |
| Talk time | Up to 11 h 40 min (2G) / Up to 17 h 30 min (3G) | |
| Misc | SAR | 0.81 W/kg (head) 0.35 W/kg (body) |
| Price | About 230 EUR | |
| Colors | Mineral black, Platinum, Forest blue, Deep pink | |
| Models | F8331, F8332, SO-01J, SOV34, 601SO | |
| SAR EU | 0.85 W/kg (head) 1.20 W/kg (body) | |
| Our Tests | Camera | Photo / Video |
| Display | Contrast ratio: 1349 (nominal), 3.795 (sunlight) | |
| Loudspeaker | Voice 61dB / Noise 65dB / Ring 67dB | |
| Performance | Basemark OS II 2.0: 2151 Basemark X: 29548 | |
| Audio quality | Noise -93.0dB / Crosstalk -93.6dB | |
| Battery (old) | Endurance rating 72h |
