Complete specification
| Section | Specification | Details |
|---|---|---|
| Network | Speed | HSPA, LTE, 5G |
| 2G bands | GSM 850 / 900 / 1800 / 1900 | |
| 3G bands | HSDPA 850 / 900 / 1700(AWS) / 1900 / 2100 | |
| 4G bands | 1, 2, 3, 4, 5, 7, 8, 12, 13, 17, 20, 25, 26, 28, 32, 38, 40, 41, 66, 68 | |
| 5G bands | 1, 3, 5, 7, 8, 20, 28, 38, 40, 41, 66, 77, 78 SA/NSA | |
| Technology | GSM / HSPA / LTE / 5G | |
| Launch | Status | Available. Released 2025, May 07 |
| Announced | 2025, April 14 | |
| Body | SIM | · Nano-SIM + eSIM · Nano-SIM + Nano-SIM |
| Weight | 240 g (8.47 oz) | |
| Dimensions | 168.6 x 79.9 x 10.2 mm (6.64 x 3.15 x 0.40 in) | |
| [bodyother] | IP68 dust tight and water resistant (immersible up to 1.5m for 30 min) Drop resistant up to 1.5m MIL-STD-810H compliant | |
| Display | Size | 6.6 inches, 104.9 cm2 (~77.9% screen-to-body ratio) |
| Type | PLS LCD, 120Hz | |
| Protection | Corning Gorilla Glass Victus+, Mohs level 5 | |
| Resolution | 1080 x 2408 pixels, 20:9 ratio (~400 ppi density) | |
| Platform | OS | Android 15, upgradable to Android 16, One UI 8 |
| CPU | Octa-core (1x2.5 GHz Cortex-A720 & 3x2.4 GHz Cortex-A720 & 4x1.8 GHz Cortex-A520) | |
| GPU | Adreno 810 | |
| Chipset | Qualcomm SM7635 Snapdragon 7s Gen 3 (4 nm) | |
| Memory | Internal | 128GB 6GB RAM, 256GB 8GB RAM |
| Card slot | microSDXC (dedicated slot) | |
| Main Camera | Dual | 50 MP, f/1.8, (wide), 1/2.76", 0.64µm, PDAF 8 MP, f/2.2, (ultrawide) |
| Video | 4K@30fps, 1080p@30fps | |
| Features | Dual-LED flash, HDR, panorama | |
| Selfie camera | Video | 1080p@30fps |
| Single | 13 MP, f/2.2, (wide) | |
| Sound | 3.5mm jack | No |
| Loudspeaker | Yes, with stereo speakers (with Dolby Atmos) | |
| Comms | NFC | Yes |
| USB | USB Type-C 3.2, charging connector pins | |
| WLAN | Wi-Fi 802.11 a/b/g/n/ac/6e, tri-band, Wi-Fi Direct | |
| Radio | No | |
| Bluetooth | 5.4, A2DP, LE | |
| Positioning | GPS, GLONASS, BDS, GALILEO, QZSS | |
| Features | Sensors | Fingerprint (side-mounted), accelerometer, gyro, proximity, compass |
| [featuresother] | Samsung DeX (desktop experience support) | |
| Battery | Type | Li-Po 4350 mAh, removable |
| Charging | 15W wired | |
| Misc | Price | $ 424.99 / € 399.99 |
| Colors | Black | |
| Models | SM-G766B, SM-G766BU1, SM-G766B/DS | |
| SAR EU | 0.81 W/kg (head) 1.03 W/kg (body) | |
| EU LABEL | Energy | Class B |
| Battery | 38:15h endurance, 2000 cycles | |
| Free fall | Class A (270 falls) | |
| Repairability | Class B |
