Complete specification
| Section | Specification | Details |
|---|---|---|
| Network | Speed | HSPA 42.2/5.76 Mbps, LTE Cat4 150/50 Mbps - cellular model only |
| 2G bands | GSM 850 / 900 / 1800 / 1900 | |
| 3G bands | HSDPA 850 / 900 / 1900 / 2100 | |
| 4G bands | 1, 2, 3, 4, 5, 7, 8, 17, 20 | |
| Technology | GSM / HSPA / LTE | |
| Launch | Status | Discontinued |
| Announced | 2015, July. Released 2015, September | |
| Body | SIM | Nano-SIM (cellular model only) |
| Weight | 389g (Wi-Fi) / 392g (LTE) (13.72 oz) | |
| Dimensions | 237.3 x 169 x 5.6 mm (9.34 x 6.65 x 0.22 in) | |
| Display | Size | 9.7 inches, 291.4 cm2 (~72.7% screen-to-body ratio) |
| Type | Super AMOLED | |
| Resolution | 1536 x 2048 pixels, 4:3 ratio (~264 ppi density) | |
| Platform | OS | Android 5.0.2 (Lollipop), upgradable to 6.0.1 (Marshmallow) - T810, T815 Android 6.0.1 (Marshmallow), upgradable to 7.0 (Nougat) - T813N, T819N |
| CPU | Octa-core (4x1.9 GHz & 4x1.3 GHz) - T810, T815 Octa-core (4x1.8 GHz Cortex-A72 & 4x1.4 GHz Cortex-A53) - T813N, T819N | |
| GPU | Mali-T760 MP6 - T810, T815 Adreno 510 - T813N, T819N | |
| Chipset | Exynos 5433 - T810, T815 Qualcomm MSM8976 Snapdragon 652 (28 nm) - T813N, T819N | |
| Memory | Internal | 16GB 3GB RAM, 32GB 3GB RAM, 64GB 3GB RAM |
| Card slot | microSDXC (dedicated slot) | |
| [memoryother] | eMMC 5.0 or eMMC 5.1 | |
| Main Camera | Video | 1440p@30fps |
| Single | 8 MP, AF | |
| Selfie camera | Single | 2.1 MP |
| Sound | 3.5mm jack | Yes |
| Loudspeaker | Yes | |
| Comms | NFC | No |
| USB | microUSB 2.0 (MHL TV-out) | |
| WLAN | Wi-Fi 802.11 a/b/g/n/ac, dual-band, Wi-Fi Direct | |
| Radio | No | |
| Bluetooth | 4.1, A2DP, LE | |
| Positioning | GPS, GLONASS - cellular model only | |
| Features | Sensors | Fingerprint (front-mounted), accelerometer, gyro, compass |
| [featuresother] | ANT+ | |
| Battery | Type | Li-Ion 5870 mAh, non-removable |
| Talk time | Up to 12 h (multimedia) (2G) / Up to 30 h (3G) | |
| Music play | Up to 109 h | |
| Misc | Price | About 270 EUR |
| Colors | White, black, gold | |
| Models | SM-T810, SM-T815, SM-T813N, SM-T819N, SM-T819, SM-T813, SM-T815Y, SM-T819Y, SM-T818V | |
| SAR EU | 0.86 W/kg (body) |
