Complete specification
| Section | Specification | Details |
|---|---|---|
| Network | EDGE | No |
| GPRS | No | |
| 2G bands | N/A | |
| Technology | No cellular connectivity | |
| Launch | Status | Discontinued |
| Announced | 2014, January. Released 2014, March | |
| Body | SIM | No |
| Weight | 469 g (1.03 lb) | |
| Dimensions | 243.1 x 171.4 x 7.3 mm (9.57 x 6.75 x 0.29 in) | |
| Display | Size | 10.1 inches, 295.8 cm2 (~71.0% screen-to-body ratio) |
| Type | Super clear LCD | |
| Resolution | 2560 x 1600 pixels, 16:10 ratio (~299 ppi density) | |
| Platform | OS | Android 4.4 (KitKat), TouchWiz UI |
| CPU | Octa-core (4x1.9 GHz Cortex-A15 & 4x1.3 GHz Cortex-A7) | |
| GPU | Mali-T628 MP6 | |
| Chipset | Exynos 5420 Octa (28 nm) | |
| Memory | Internal | 16GB 2GB RAM, 32GB 2GB RAM |
| Card slot | microSDXC (dedicated slot) | |
| Main Camera | Video | 1080p@30fps |
| Single | 8 MP, AF | |
| Features | LED flash | |
| Selfie camera | Video | 1080p@30fps |
| Single | 2 MP | |
| Sound | 3.5mm jack | Yes |
| Loudspeaker | Yes, with stereo speakers | |
| Comms | NFC | No |
| USB | microUSB 2.0 (MHL TV-out), OTG | |
| WLAN | Wi-Fi 802.11 a/b/g/n/ac, dual-band, Wi-Fi Direct, hotspot | |
| Radio | No | |
| Bluetooth | 4.0, A2DP | |
| Positioning | GPS, GLONASS | |
| Infrared port | Yes | |
| Features | Sensors | Accelerometer, gyro, compass |
| Battery | Type | Li-Ion 8220 mAh, non-removable |
| Talk time | Up to 10 h (multimedia) | |
| Music play | Up to 147 h | |
| Misc | SAR | 0.80 W/kg (body) |
| Price | About 360 EUR | |
| Colors | Black, White | |
| Models | SM-T520 | |
| SAR EU | 0.30 W/kg (body) | |
| Our Tests | Display | Contrast ratio: 812:1 (nominal) |
| Loudspeaker | Voice 67dB / Noise 66dB / Ring 69dB | |
| Audio quality | Noise -93.2dB / Crosstalk -94.4dB |
