Complete specification
| Section | Specification | Details |
|---|---|---|
| Network | Speed | HSPA - cellular model only |
| 2G bands | GSM 850 / 900 / 1800 / 1900 | |
| 3G bands | HSDPA 900 / 2100 | |
| Technology | GSM / HSPA | |
| Launch | Status | Discontinued |
| Announced | 2015, June. Released 2015, July | |
| Body | SIM | Micro-SIM - cellular model only |
| Build | Glass front, plastic back, plastic frame | |
| Weight | 490 g (Wi-Fi)/ 495 g (3G) (1.08 lb) | |
| Dimensions | 241.9 x 149.5 x 8.5 mm (9.52 x 5.89 x 0.33 in) | |
| Display | Size | 9.6 inches, 267.2 cm2 (~73.9% screen-to-body ratio) |
| Type | TFT | |
| Resolution | 800 x 1280 pixels, 16:10 ratio (~157 ppi density) | |
| Platform | OS | Android 4.4 (KitKat) - EU model Android 5.1 (Lollipop), upgradable to 7.0 (Nougat) - USA model |
| CPU | Quad-core 1.3 GHz Quad-core 1.2 GHz - USA model | |
| Memory | Internal | 8GB 1.5GB RAM, 16GB 1.5GB RAM |
| Card slot | microSDXC (dedicated slot) | |
| Main Camera | Video | 720p@30fps |
| Single | 5 MP, f/2.2, AF | |
| Selfie camera | Single | 2 MP, f/2.4 |
| Sound | 3.5mm jack | Yes |
| Loudspeaker | Yes | |
| Comms | NFC | No |
| USB | microUSB 2.0 | |
| WLAN | Wi-Fi 802.11 b/g/n, Wi-Fi Direct, hotspot Wi-Fi 802.11 a/b/g/n, Wi-Fi Direct, hotspot - USA model | |
| Radio | No | |
| Bluetooth | 4.0, A2DP; 4.1, A2DP - USA model | |
| Positioning | GPS, GLONASS, BDS - cellular model only | |
| Features | Sensors | Accelerometer |
| Battery | Type | Li-Ion 5000 mAh, non-removable,Non-removable Li-Ion 7300 mAh battery - USA model |
| Talk time | Up to 7 h 30 min (multimedia) (2G) / Up to 26 h (3G),Up to 12 h (multimedia) | |
| Music play | Up to 95 h | |
| Misc | Price | About 200 EUR |
| Colors | Pearl White, Metallic Black | |
| Models | SM-T560, SM-T561, SM-T560NU | |
| SAR EU | 0.50 W/kg (body) |
