Complete specification
| Section | Specification | Details |
|---|---|---|
| Network | Speed | HSPA 42.2/11.5 Mbps, LTE Cat4 150/50 Mbps |
| 2G bands | GSM 850 / 900 / 1800 / 1900 | |
| 3G bands | HSDPA 850 / 900 / 1900 / 2100 | |
| 4G bands | 25, 26, 41 | |
| Technology | GSM / CDMA / HSPA / LTE | |
| Launch | Status | Discontinued |
| Announced | 2014, June. Released 2014, June | |
| Body | SIM | Micro-SIM |
| Weight | 158 g (5.57 oz) | |
| Dimensions | 144 x 74 x 8.9 mm (5.67 x 2.91 x 0.35 in) | |
| [bodyother] | IP67 dust/water resistant (up to 1m for 30 min) | |
| Display | Size | 5.1 inches, 71.7 cm2 (~67.3% screen-to-body ratio) |
| Type | Super AMOLED | |
| Protection | Corning Gorilla Glass 3 | |
| Resolution | 1080 x 1920 pixels, 16:9 ratio (~432 ppi density) | |
| Platform | OS | Android 4.4.2 (KitKat), upgradable to 6.0 (Marshmallow), TouchWiz UI |
| CPU | Quad-core 2.5 GHz Krait 400 | |
| GPU | Adreno 330 | |
| Chipset | Qualcomm Snapdragon 801 (28 nm) | |
| Memory | Internal | 16GB 2GB RAM |
| Card slot | microSDXC (dedicated slot) | |
| [memoryother] | eMMC 5.0 | |
| Main Camera | Video | 4K@30fps, 1080p@30fps |
| Single | 16 MP, 1/2.6", 1.12µm, AF | |
| Features | LED flash, panorama, HDR | |
| Selfie camera | Video | 1080p@30fps |
| Single | 2 MP | |
| Sound | 3.5mm jack | Yes |
| Loudspeaker | Yes | |
| Comms | NFC | Yes |
| USB | microUSB 2.0 (MHL 2.1 TV-out), OTG | |
| WLAN | Wi-Fi 802.11 a/b/g/n/ac, dual-band, Wi-Fi Direct, hotspot | |
| Radio | No | |
| Bluetooth | 4.0, A2DP, EDR, LE, aptX | |
| Positioning | GPS, GLONASS | |
| Features | Sensors | Accelerometer, gyro, proximity, compass, barometer, heart rate |
| [featuresother] | ANT+ | |
| Battery | Type | Li-Ion 2800 mAh, removable |
| Talk time | Up to 29 h (3G) | |
| Music play | Up to 77 h | |
| Misc | SAR | 1.25 W/kg (head) 1.30 W/kg (body) |
| Price | About 300 EUR | |
| Colors | Electric Blue, Cherry Red | |
| Models | SM-G860, SM-G860P | |
| SAR EU | 0.51 W/kg (head) 0.47 W/kg (body) |
