Complete specification
| Section | Specification | Details |
|---|---|---|
| Network | Speed | HSPA 42.2/5.76 Mbps, LTE Cat4 150/50 Mbps |
| 2G bands | GSM 850 / 900 / 1800 / 1900 - SIM 1 & SIM 2 (dual-SIM model only) | |
| 3G bands | HSDPA 850 / 900 / 1900 / 2100 | |
| 4G bands | 1, 3, 5, 7, 8, 20 | |
| Technology | GSM / HSPA / LTE | |
| Launch | Status | Discontinued |
| Announced | 2016, March 31. Released 2016, May 06 | |
| Body | SIM | · Micro-SIM · Micro-SIM + Micro-SIM · Nano-SIM (USA models only) |
| Build | Glass front (Asahi Dragontrail), plastic back, plastic frame | |
| Weight | 138 g (4.87 oz) | |
| Dimensions | 142.3 x 71 x 7.9 mm (5.60 x 2.80 x 0.31 in) | |
| Display | Size | 5.0 inches, 68.9 cm2 (~68.2% screen-to-body ratio) |
| Type | Super AMOLED | |
| Protection | Asahi Dragontrail Glass | |
| Resolution | 720 x 1280 pixels, 16:9 ratio (~294 ppi density) | |
| Platform | OS | Android 5.1.1 (Lollipop) or Android 6.0 (Marshmallow), upgradable to 7.1.1 (Nougat) |
| CPU | Quad-core 1.5 GHz Cortex-A7 Quad-core 1.3 GHz Cortex-A7 - USA | |
| GPU | Mali-400 Mali-T720 - USA | |
| Chipset | Spreadtrum SC9830 Exynos 3475 Quad (28 nm) - USA | |
| Memory | Internal | 8GB 1.5GB RAM, 16GB 2GB RAM |
| Card slot | microSDXC (dedicated slot) | |
| [memoryother] | eMMC 4.5 | |
| Main Camera | Video | 720p@30fps |
| Single | 8 MP, f/2.2, AF 5 MP, f/2.2, AF - USA | |
| Features | LED flash, HDR | |
| Selfie camera | Video | 720p@30fps |
| Single | 2 MP (USA) 5 MP, f/2.2 (all other regions) | |
| Sound | 3.5mm jack | Yes |
| Loudspeaker | Yes | |
| Comms | NFC | Yes (market dependent) |
| USB | microUSB 2.0, OTG | |
| WLAN | Wi-Fi 802.11 b/g/n, Wi-Fi Direct | |
| Radio | FM radio, RDS, recording (market dependent) | |
| Bluetooth | 4.0/4.1, A2DP, LE | |
| Positioning | GPS, GLONASS | |
| Features | Sensors | Accelerometer, proximity |
| Battery | Type | Li-Ion 2600 mAh, removable |
| Stand-by | Up to 349 h | |
| Talk time | Up to 22 h | |
| Music play | Up to 77 h | |
| Misc | SAR | 1.17 W/kg (head) 1.12 W/kg (body) |
| Price | About 120 EUR | |
| Colors | White, Black, Gold | |
| Models | SM-J320H, SM-J3109, SM-J320FN, SM-J320P, SM-J320F, SM-J320M, SM-J320Y, SM-J320A, SM-J320G, SM-J327T1, SM-J320V, SM-J320YZ, SM-J320W8, SM-J320ZN, SM-J320N0, SM-J320R4 | |
| SAR EU | 0.48 W/kg (head) 0.42 W/kg (body) | |
| Our Tests | Camera | Photo / Video |
| Display | Contrast ratio: Infinite (nominal), 3.523 (sunlight) | |
| Loudspeaker | Voice 64dB / Noise 65dB / Ring 68dB | |
| Performance | Basemark OS II 2.0: 326 Basemark X: 1424 | |
| Audio quality | Noise -92.4dB / Crosstalk -91.3dB | |
| Battery (old) | Endurance rating 66h |
