Complete specification
| Section | Specification | Details |
|---|---|---|
| Network | Speed | HSPA, LTE |
| 2G bands | GSM 850 / 900 / 1800 / 1900 - SIM 1 & SIM 2 (dual-SIM model only) | |
| 3G bands | HSDPA 850 / 900 / 1700(AWS) / 1900 / 2100 | |
| 4G bands | 1, 2, 3, 4, 5, 7, 8, 12, 17, 19, 20, 28, 38, 40 - USA | |
| Technology | GSM / CDMA / HSPA / LTE | |
| Launch | Status | Discontinued |
| Announced | 2016, August. Released 2016, September | |
| Body | SIM | · Nano-SIM · Nano-SIM + Nano-SIM |
| Build | Glass front (Gorilla Glass 3), glass back, aluminum frame | |
| Weight | 165 g (5.82 oz) | |
| Dimensions | 156.4 x 76.4 x 7 mm (6.16 x 3.01 x 0.28 in) | |
| [bodyother] | Splash and dust resistant | |
| Display | Size | 5.5 inches, 82.6 cm2 (~69.1% screen-to-body ratio) |
| Type | Super AMOLED | |
| Protection | Corning Gorilla Glass 3 | |
| Resolution | 1080 x 1920 pixels, 16:9 ratio (~403 ppi density) | |
| Platform | OS | Android 6.0.1 (Marshmallow), upgradable to Android 8.0 (Oreo) |
| CPU | Octa-core 2.0 GHz Cortex-A53 | |
| GPU | Adreno 506 | |
| Chipset | Qualcomm MSM8953 Snapdragon 625 (14 nm) | |
| Memory | Internal | 32GB 3GB RAM |
| Card slot | microSDXC (dedicated slot) | |
| [memoryother] | eMMC 5.1 | |
| Main Camera | Video | 4K@30fps, 1080p@30fps, 720p@120fps |
| Single | 16 MP, f/2.0, 1.3µm, PDAF | |
| Features | Laser AF, Dual-LED dual-tone flash, panorama | |
| Selfie camera | Video | 1080p@30fps |
| Single | 5 MP, f/2.2, 1/4.0", 1.4µm | |
| Features | LED flash | |
| Sound | 3.5mm jack | Yes |
| Loudspeaker | Yes | |
| Comms | NFC | Yes |
| USB | USB Type-C, magnetic connector | |
| WLAN | Wi-Fi 802.11 a/b/g/n, Wi-Fi Direct | |
| Radio | No | |
| Bluetooth | 4.0, A2DP, LE, aptX | |
| Positioning | GPS, GLONASS | |
| Features | Sensors | Fingerprint (front-mounted), accelerometer, gyro, proximity, compass |
| [featuresother] | Moto Mods snap-on accessories | |
| Battery | Type | Li-Ion 3510 mAh, non-removable |
| Charging | 15W wired | |
| Misc | SAR | 1.45 W/kg (head) 1.15 W/kg (body) |
| Price | About 220 EUR | |
| Colors | Black/Silver/Black Slate, White/Fine Gold/Sugar White | |
| Models | XT1635-02, XT1635-01, XT1635-03 | |
| SAR EU | 0.40 W/kg (head) 1.40 W/kg (body) | |
| Our Tests | Camera | Photo / Video |
| Display | Contrast ratio: Infinite (nominal), 3.526 (sunlight) | |
| Performance | GFXBench: 3.7fps (ES 3.1 onscreen) | |
| Audio quality | Noise-93.0dB / Crosstalk -93.8dB | |
| Battery (old) | Endurance rating 100h |
