Complete specification
| Section | Specification | Details |
|---|---|---|
| Network | Speed | HSPA 42.2/5.76 Mbps, LTE (3CA) Cat9 450/50 Mbps |
| 2G bands | GSM 850 / 900 / 1800 / 1900 - EMEA, USA | |
| 3G bands | HSDPA 850 / 900 / 1900 / 2100 - EMEA, USA | |
| 4G bands | 2, 3, 4, 5, 7, 13 - USA | |
| Technology | GSM / CDMA / HSPA / EVDO / LTE | |
| Launch | Status | Discontinued |
| Announced | 2016, June. Released 2016, September | |
| Body | SIM | Nano-SIM |
| Weight | 163 g (5.75 oz) | |
| Dimensions | 155.9 x 75.8 x 7 mm (6.14 x 2.98 x 0.28 in) | |
| Display | Size | 5.5 inches, 83.1 cm2 (~70.3% screen-to-body ratio) |
| Type | AMOLED | |
| Protection | Shatterproof | |
| Resolution | 1440 x 2560 pixels, 16:9 ratio (~535 ppi density) | |
| Platform | OS | Android 6.0.1 (Marshmallow), upgradable to Android 8.0 (Oreo) |
| CPU | Quad-core (2x2.15 GHz Kryo & 2x1.6 GHz Kryo) | |
| GPU | Adreno 530 | |
| Chipset | Qualcomm MSM8996 Snapdragon 820 (14 nm) | |
| Memory | Internal | 32GB 4GB RAM, 64GB 4GB RAM |
| Card slot | microSDXC (dedicated slot) | |
| Main Camera | Video | 4K@30fps, 1080p@30/60fps, HDR |
| Single | 21 MP, f/1.8, 1.12µm, PDAF, OIS | |
| Features | Laser AF, Dual-LED dual-tone flash, panorama, HDR | |
| Selfie camera | Video | 1080p@30fps |
| Single | 5 MP, f/2.2, 1/4.0", 1.4µm | |
| Features | LED flash | |
| Sound | 3.5mm jack | No |
| Loudspeaker | Yes | |
| Comms | NFC | Yes |
| USB | USB Type-C, OTG, magnetic connector | |
| WLAN | Wi-Fi 802.11 a/b/g/n/ac, dual-band, Wi-Fi Direct | |
| Radio | No | |
| Bluetooth | 4.1, A2DP, EDR, LE, aptX | |
| Positioning | GPS, GLONASS | |
| Features | Sensors | Fingerprint (front-mounted), accelerometer, gyro, proximity, compass |
| [featuresother] | Moto Mods snap-on accessories | |
| Battery | Type | Li-Ion 3500 mAh, non-removable |
| Charging | 15W wired | |
| Misc | Price | About 270 EUR |
| Colors | Black/Gray, Black/Rose Gold, Black/Gold, White | |
| Our Tests | Loudspeaker | Voice 69dB / Noise 68dB / Ring 77dB |
| Performance | Basemark OS II 2.0: 5395 Basemark X: 36405 | |
| Audio quality | Noise -94dB / Crosstalk -94.9dB | |
| Battery (old) | Endurance rating 88h |
