Complete specification
| Section | Specification | Details |
|---|---|---|
| Network | Speed | HSPA 42.2/5.76 Mbps, LTE (2CA) Cat6 300/50 Mbps, EV-DO Rev.A 3.1 Mbps |
| 2G bands | GSM 850 / 900 / 1800 / 1900 - SIM 1 & SIM 2 (dual-SIM model only) | |
| 3G bands | HSDPA 850 / 900 / 1700(AWS) / 1900 / 2100 - XT1687 (USA) | |
| 4G bands | 1, 2, 3, 4, 5, 7, 8, 12, 13, 17, 25, 26, 38, 41, 66 - XT1687 (USA) | |
| Technology | GSM / CDMA / HSPA / EVDO / LTE | |
| Launch | Status | Discontinued |
| Announced | 2017, February. Released 2017, April | |
| Body | SIM | · Nano-SIM · Nano-SIM + Nano-SIM |
| Build | Glass front (Gorilla Glass 3), aluminum back, plastic frame | |
| Weight | 155 g (5.47 oz) | |
| Dimensions | 150.2 x 74 x 7.7 mm (5.91 x 2.91 x 0.30 in) | |
| [bodyother] | Splash and dust resistant | |
| Display | Size | 5.2 inches, 74.5 cm2 (~67.1% screen-to-body ratio) |
| Type | IPS LCD | |
| Protection | Corning Gorilla Glass 3 | |
| Resolution | 1080 x 1920 pixels, 16:9 ratio (~424 ppi density) | |
| Platform | OS | Android 7.0 (Nougat), upgradable to Android 8.1 (Oreo) |
| CPU | Octa-core 2.0 GHz Cortex-A53 | |
| GPU | Adreno 506 | |
| Chipset | Qualcomm MSM8953 Snapdragon 625 (14 nm) | |
| Memory | Internal | 32GB 2GB RAM, 32GB 3GB RAM, 64GB 4GB RAM |
| Card slot | microSDXC (dedicated slot) | |
| [memoryother] | eMMC 5.1 | |
| Main Camera | Video | 4K@30fps, 1080p@60fps |
| Single | 12 MP, f/1.7, dual pixel PDAF | |
| Features | Dual-LED dual-tone flash, panorama | |
| Selfie camera | Video | 1080p@30fps, 480p@120fps |
| Single | 5 MP, f/2.2 | |
| Sound | 3.5mm jack | Yes |
| Loudspeaker | Yes | |
| Comms | NFC | Yes (market dependent) |
| USB | microUSB 2.0, OTG | |
| WLAN | Wi-Fi 802.11 a/b/g/n, dual-band, Wi-Fi Direct | |
| Radio | FM radio | |
| Bluetooth | 4.2, A2DP, LE, EDR, aptX | |
| Positioning | GPS, GLONASS | |
| Features | Sensors | Fingerprint (front-mounted), accelerometer, gyro, proximity, compass (USA model only) |
| Battery | Type | Li-Ion 3000 mAh, non-removable |
| Charging | 15W wired | |
| Misc | SAR | 0.09 W/kg (head) 1.18 W/kg (body) |
| Price | About 240 EUR | |
| Colors | Lunar Grey, Fine Gold | |
| Models | XT1685, XT1687, XT1684, XT1686 | |
| SAR EU | 0.30 W/kg (head) 1.24 W/kg (body) | |
| Our Tests | Performance | GeekBench: 4255 (v4.4) GFXBench: 3.5fps (ES 3.1 onscreen) |
