Complete specification
| Section | Specification | Details |
|---|---|---|
| Launch | Status | Available. Released 2015, February |
| Announced | 2015, January | |
| Release date | 01 January 2015 | |
| Display | Size | 5.5 inches, 82.6 cm (~73.5% screen-to-body ratio) |
| Protection | Corning Gorilla Glass 3 | |
| Resolution | 1080 x 1920 pixels, 16:9 ratio (~403 ppi density) | |
| Technology | Curved P-OLED capacitive touchscreen, 16M colors | |
| Aspect ratio | 18:9 | |
| Refresh rate | 30 Hz | |
| Pixel density | 401 ppi | |
| Screen to body ratio | 74.1 % | |
| Memory | RAM | 2 GB RAM/ 32 GB| 3 GB RAM |
| Card | microSD, up to 256 GB (dedicated slot) | |
| Built-in | 16 GB, 2 GB RAM/ 32 GB, 3 GB RAM | |
| RAM type | LPDDR4 | |
| Storage type | eMMC 5.0 | |
| Storage variants | 16 GB, 2 GB RAM/ 32 GB, 3 GB RAM | 32GB 3GB RAM | 16GB 2GB RAM, 32GB 3GB RAM | |
| Sound | 3 5mm Jack | Yes |
| Audio jack | 3.5 mm | |
| Loudspeaker | Yes | |
| Additional features | Dolby mobile Active noise cancellation with dedicated mic | |
| Features | Sensors | Accelerometer, gyro, proximity, compass, color spectrum |
| Additional features | DMB TV tuner (Korean model only) | |
| Battery | Capacity | Non-removable Li-Po 3000 mAh battery |
| Charging | Fast battery charging 18W (Quick Charge 2.0) | |
| Stand By | Up to 520 h (2G) / Up to 450 h (3G) | |
| Talk Time | Up to 18 h (2G) / Up to 20 h (3G) | |
| Misc | Sar | 1.10 W/kg (head) 1.07 W/kg (body) |
| Models | F510, LS996, H950, H955, US995 | |
| Sar Eu | 0.68 W/kg (head) 0.44 W/kg (body) | |
| Build | OS | Android 5.0.1 (Lollipop), upgradable to 6.0.1 (Marshmallow) |
| SIM | Micro-SIM | |
| Build | Curved body and display | |
| Colors | Platinum Silver, Flamenco Red | |
| Weight | 152 g (5.36 oz) | |
| SIM size | SIM1: Micro | |
| Dimensions | 149.1 x 75.3 x 9.4 mm (5.87 x 2.96 x 0.37 in) | |
| Additional features | Self-healing back panel coating | |
| Price | Conversion rate | 1 EUR = 1.16 USD |
| Approx. price EUR | €270.00 | |
| Approx. price USD | $313.20 | |
| Tests | Camera | Photo / Video |
| Battery Life | Endurance rating 62h | |
| Camera | Main | 13 MP, f/2.4, OIS, laser AF |
| Front | 2.1 MP | |
| Video | 2160p@30fps, 1080p@60fps, HDR, stereo sound rec. | |
| Features | Dual-LED flash, panorama, HDR | |
| Front video | 1080p@30fps | |
| Frequency | Edge | Yes |
| Gprs | Yes | |
| Speed | HSPA 42.2/21.1 Mbps, LTE-A Cat6 300/50 MbpsLTE-A, EV-DO Rev.A 3.1 Mbps - US995 (U.S. Cellular) | |
| 2G Band | GSM 850 / 900 / 1800 / 1900 | |
| 3G Band | HSDPA 850 / 900 / 1900 / 2100 | |
| 4G Band | LTE band 1(2100), 3(1800), 7(2600), 8(900), 20(800) - H955 | |
| Technology | GSM / CDMA / HSPA / EVDO / LTE | |
| Additional features | LTE - US995 (U.S. Cellular) | |
| Processor | CPU | Octa-core (4x1.5 GHz Cortex-A53 & 4x2.0 GHz Cortex-A57) |
| GPU | Adreno 430 | |
| Chipset | Qualcomm MSM8994 Snapdragon 810 (20 nm) | |
| Fabrication | 20 nm | |
| Architecture | 64 bit | |
| Connectivity | GPS | Yes, with A-GPS, GLONASS |
| NFC | Yes | |
| OTG | Yes | |
| USB | microUSB 2.0 (SlimPort), USB Host | |
| WLAN | Wi-Fi 802.11 a/b/g/n/ac, dual-band, Wi-Fi Direct, DLNA, hotspot | |
| Radio | Stereo FM radio, RDS | |
| Bluetooth | 4.1, A2DP, LE, aptX | |
| Infrared Port | Yes |
